Previous version of NMEA is the 0183 standard. NMEA 2000 is the latest version of NMEA which is the marine industry standard for the way electronics and marine instruments talk communicate to each other. Next time you are in the market for a new addition to your boats marine electronics package and are looking at the latest offerings you may see the label NMEA 2000 compliant. For Raymarine RayNet, use cables with Raymarine part numbers A62360, A80151, A80159 for Raymarine SeaTalk HS use cables with part numbers E55049, E55050, E55051.NMEA 2000 protocol.

#Opencpn nmea 2000 network Pc#

Note that Ethernet cable is not supplied with the Gateway, for direct connection with a PC or Garmin Marine Network, a regular RJ45 Male-Male Cat 5e/6 cable is required (can be purchased in any computer store). Drawing of NMEA 2000 Ethernet Gateway YDEN-02 For other networks, an adaptor cable may be required. The Ethernet Gateway is supplied with a connector compatible with Raymarine SeaTalk NG or NMEA 2000 Micro Male connector (see the picture below).

pair of Gateways can bridge two NMEA 2000 segments over Ethernet.

powered from NMEA 2000, low power consumption (less than 50 mA).

support mDNS and Bonjour protocols for easy discovery in the network.

provides high-voltage galvanic isolation between NMEA 2000 and Ethernet interfaces.

is compatible with 10 Mb/s, 100 Mb/s and 1000 Mb/s Ethernet networks.

can be configured for static IP address, or to obtain an IP automatically, or work as a DHCP server.

To learn more about Cloud Services, visit: Cloud Services allows easy access to your tracks from home and lets you share your position with family and friends. If the Gateway has an internet connection, it can automatically upload recorded data to Cloud Services.

Screenshots of administrative web site (use slider)

NMEA data servers (TCP or UDP network protocols NMEA 0183, NMEA 2000 (RAW), Memory or Debug data protocols) If you have access to your boat Ethernet network over the internet, Web Gauges are a ready solution to monitor and manage your vessel. The Web Gauges page of the built-in web site allows managing of a digital switching equipment and real time viewing of vessel data using a web browser on PC, laptop, tablet or smartphone no internet connection or app installation is required. NMEA 2000 Ethernet Gateway with different connectors ( click to enlarge) The Gateway has three data servers (TCP/UDP), which allows tailored settings for different applications. OpenCPN (NMEA 0183 only) and Expedition 10 (both NMEA 0183 and NMEA 2000 protocols are supported). This allows viewing of navigational data including AIS as well as managing NMEA equipment including autopilot from virtually all marine software, e.g. The Device provides NMEA 0183 and NMEA 2000 data streams using TCP and/or UDP protocols, and has a bi-directional converter between NMEA 0183 and NMEA 2000. The Gateway is equipped with a standard Ethernet RJ45 connector, and you may need a proprietary adapter to connect it with your vessel’s network direct connection to PC with standard computer cable is also supported.

The Gateway connects navigation PCs and laptops to NMEA 2000 over Ethernet, Garmin Marine Network, Raymarine SeaTalk HS and RayNet, Furuno NavNet, or NMEA OneNet, and allows bridging of NMEA 2000 networks. Description NMEA 2000 Ethernet Gateway YDEN-02
